PCR workstation

PCR workstation

PCR workstation are used for PCR diagnosis for work with DNA samples under sterile conditions. The workstation guarantees the protection of a product from dirt, while the protection of an operator and environment is not provided.

The principle of operation lies in the creation of antibacterial environment in the operating zone with the help of hard UV irradiation.

Peculiarities of construction of the Kupertek Calm PCR workstation:

  • The position of the light source for the operating zone eliminates a possibility of eye injuries from ultraviolet;
  • Metal housing guarantees the complete absence of emission from the surface and makes cleaning a simple task;
  • The slanted front panel improves ergonomics and allows an operator to sit normally during the work;
  • The start and the time of UV applying in the operating zone is set with the help of digital timer allowing for the setup of up to 8 programmes during the day.
  • Standard painting colour – RAL 7035.

Additional options:

  • Bench support with adjustable rests and rollers;
  • Power board installed on the back panel of the operating zone;
  • Painting according to customer’s choice.

ПЦР-бокспцр-шафапцр бокс

Key features of the Kupertek Calm PCR workstation:

Parameter

Parameter value

Kupertek Calm 900

Kupertek Calm 1200

Operating chamber size, mm, minimum:

- width

- depth

- height



900

540

670



1200

540

670

Overall dimensions of workstation, mm, maximum:

- width

- depth

- height



906

585

800



1206

585

800

Overall dimensions of stand, mm, maximum:

- width

- depth

- height



906

585

755



1206

585

755

Mass without bench support, kg

45

53

Illuminating lamp type

LED, 6500K, 9W/G13

Germicidal lamp type

PHILIPS TUV 15W/G13 T8

Power consumption of workstation, W, maximum

30

Supply voltage, V

~ 220 ± 5%

Frequency, Hz

50 ± 0,5


During the development and production of PCR workstations we are seeking to seamlessly combine design, ergonomics, technological effectiveness and final cost of products.
PCR workstation production duration according to customer’s order is up to 20 business days.
A workstation is delivered to a customer in Ukraine only in rigid package. Delivery in Kharkiv may be an exception.
The product has   certificate>>sanitary and epidemiological expertise report >> and technical specifications.>>.



Workstations selection according to protection purposes:

Workstation model

Protection

Operator

Environment

Product

БЛ-2

Breva>>

P

P

P

БЛ-1

Breeze>>



P

P

ББ-1

Bora>>

P

P



ВШ-1

Tornado>>

P





Б-1

Calm>>





P
