Fume hood
Fume hood is intended for the protection of an operator during the work with hazardous chemicals and slightly toxic substances providing their effective removal from operating zone.
As a rule, it is used during works connected with liberation of fumes and gases that are harmful for human health, as well as during the works with substances requiring removal of by-products.
Fume hoods are intended for use together with outer exhaust ventilation system.
Fume hood is not intended for the work with harmful and potentially harmful pathogens and microorganisms.
Distinctive features of Kupertek Tornado fume hoods:
- All-metal design of fume hoods
- Operating surface is made of stainless steel
- LED illumination
- Power board in the operating zone
- Built-in air-exhauster
- Slanted tempered glass protection screen with gas shock absorbers
- Flange for connecting to outer exhaust ventilation system
Key features of the Kupertek Tornado fume hoods:
|
Parameter |
Parameter value |
|
|
Tornado 900 |
Tornado 1200 |
|
|
Operating chamber size, mm, minimum: - width - depth - height |
900 525 680 |
1200 525 680 |
|
Overall dimensions of cabinet, mm, maximum: - width - depth - height |
906 585 900 |
1206 585 900 |
|
Overall dimensions of stand, mm, maximum: - width - depth - height |
906 665 755 |
1206 665 755 |
|
Mass without bench support, kg |
55 |
75 |
|
Fan type |
ВЕНТС ВКФ-250 |
|
|
Adjustable output of cabinet (maximum on purified air flow) |
1050 m3/hr |
|
|
Illuminating lamp type |
LED, 6500K, 9W/G13 |
|
|
Power consumption of cabinet, W, maximum |
120 |
|
|
Supply voltage, V |
~ 220 ± 5% |
|
|
Frequency, Hz |
50 ± 0,5 |
|
|
Cabinet model |
Protection |
|||
|
Operator |
Environment |
Product |
||
|
БЛ-2 |
P |
P |
P |
|
|
БЛ-1 |
|
P |
P |
|
|
ББ-1 |
P |
P |
|
|
|
ВШ-1 |
P |
|
|
|
|
Б-1 |
|
|
P |
|
