Class 1 laminar flow cabinet

Class 1 laminar flow cabinet or laminar flow hood (product protection) is intended for:

• creation of local dustless nonbacterial aerial environment;
• the work with specimens and bacterial cultures, which are not dangerous for an operator, when the protection of a work material from the environment is needed, or when the work with an item requires a sterile operating zone.

Class 1 laminar flow cabinet guarantees the protection of a product, while the protection of an operator and environment is not provided.

Peculiarities of construction of the Kupertek Breeze Laminar Flow Cabinet:

• slanted front panel improves ergonomics for an operator;
• protection glass is tempered, with gas shock absorbers;
• operating zone illumination (LED lamp, 6500К) is positioned so that it does not impede laminar flow and operator’s eyes;
• HEPA filter is protected with fine-meshed aluminum screen from accidental damages during cleaning;
• operating surface is made of polished food grade stainless steel;
• all-metal housing with powder coating allows for simple sanitization and zero emission from the surface. Standard colour – RAL7035.
• coarse purification of air – filter Ecopleat F7 (G4) – extends НЕРА filter protection period;
• purification of air entering the operating chamber – HEPA – filters H12 or H13 produced by«Selton»;
• in order to provide air flow, only the imported fans produced by Systemair are used, as they produce minimum noise;
• bench support is comfortable due to the rollers for transportation within the premises, and due to adjustment and fixation of the level with the help of adjustable rests;
• cabinet’s control system makes it possible to adjust air flow rate in the operating chamber and to set the needed on/off switching time for UV irradiation of the operating chamber;
• depth of a standard cabinet is designed so that the unit can fit a standard doorway (700mm) without the necessity to disassemble the cabinet (which can negatively affect the further efficiency of the cabinet). Standard width of the cabinet is 900mm and 1,200mm.

Additional options:

• power board installed on the back panel of the operating zone;
• filming of protective glass;
• HEPA filter H14;
• additional soundproofing;
• painting according to customer’s choice;
• production material – stainless steel.

Key features of the Kupertek Breeze Laminar Flow Cabinet:
