Class 1 biosafety cabinet

Class 1 biosafety cabinet (protection of operator and environment) is intended for:

• Physical isolation (confinement and controlled removal from the operating zone) of biological warfare agents and microorganisms in order to eliminate a possibility of airborne infection of the staff, as well as the contamination of the working premises and environment.

It is used for primary protection of an operator when equipping some work places in virological and bacteriological laboratories, in medical, pharmaceutical and other institutions for the work with biological warfare agents and microorganisms.

Peculiarities of construction of the Kupertek Bora Class 1 biosafety cabinet:

• slanted front panel improves ergonomics for an operator;
• protection glass is tempered, with gas shock absorbers;
• operating zone illumination (LED lamp, 6500К) is positioned so that it does not impede laminar flow and operator’s eyes;
• HEPA filter is protected with fine-meshed aluminum screen from accidental damages during cleaning;
• operating surface is made of polished food grade stainless steel;
• purification of air entering the operating chamber – HEPA – filters H13 or H14 produced bySelton;
• all-metal housing with powder coating allows for simple sanitization and zero emission from the surface. Standard colour – RAL7035;
• cabinet’s control system makes it possible to adjust air flow rate in the operating chamber and to set the needed on/off switching time for UV irradiation of the operating chamber;
• bench support with adjustable rests and rollers;
• depth of a standard cabinet is designed so that the unit can fit a standard doorway (700mm) without the necessity to disassemble the cabinet (which can negatively affect the further efficiency of the cabinet). Standard width of the cabinet is 900mm and 1,200mm.

Additional options:

• power board installed on the back panel of the operating zone (total consumed power shall not exceed 800W);
• filming of protective glass;
• additional soundproofing;
• painting according to customer’s choice;
• production material – stainless steel;
• width – 1,500 mm.

Key features of the Kupertek Bora Class 1 biosafety cabinet:

During the development and production of laminar flow cabinets, we are seeking to seamlessly combine design, ergonomics, technological effectiveness and final cost of products. There is a constant work aimed at the improvement of products.

Class 1 biosafety cabinet production duration according to customer’s order is up to 20 business days.

A cabinet is delivered to a customer in Ukraine only in rigid package.

The product has   certificate>>, sanitary and epidemiological expertise report >> and technical specifications.>>.
