Active pass box
Active pass box (pass box) is intended for moving materials between premises with different cleanliness classes.
Air feeding is carried out through the HEPA filter in the upper section of the box. Air exhaust is carried out through the lower section into premises with lower cleanliness class or into the general exhaust ventilation system. Shut doors are blocked with the permanent magnet, which eliminates a possibility of their simultaneous opening.
The box is applied in biotechnological, microbiological and other laboratories with high requirements to purity of air in premises.
Similar products are produced exclusively for the customer’s individual needs. Only the basic features are indicated below.
The peculiarities of the Kupertek Cavalier active pass box:
- operating zone illumination (LED lamp, 6400К) is positioned so that it does not impede laminar flow;
- absence of hidden hollows and slits that are hard to access for sanitization in the operating zone;
- electromagnetic locks on doors.
Optional for the Kupertek Cavalier active pass box:
- production material – stainless steel
- UV lamp in the operating zone;
- surface sheets for wall openings.
Key features of the Kupertek Cavalier active pass box:
|
Parameter |
Parameter value |
|
|
Operating chamber 450х450х450 mm |
Operating chamber 610х610х610 mm |
|
|
Operating chamber size, mm, minimum: - width - depth - height |
450 450 450 |
610 610 610 |
|
Overall dimensions of housing, mm, maximum: - width - depth - height |
634 544 988 |
784 694 1188 |
|
Mass (approximate), kg |
60 |
75 |
|
Service purification filter (НЕРА) |
Selton ФПП.Ж.Н14.450.П 450х390х69 mm |
Selton ФПП.Ж.Н13.1200.П 600х540х69 mm |
|
Fan type |
Systemair KV150М |
Systemair KV150XL |
|
Air purity grade according to DSTU, GOST, ISO14644-1:2004 |
5 ISO |
|
|
HEPA filters class |
EN1822 |
|
|
Adjustable output of cabinet (maximum on purified air flow) |
250 m3/hr |
520 m3/hr |
|
Illuminating lamp type |
LED, 6500K |
|
|
Germicidal lamp type (optional) |
PHILIPS TUV 15W/G13 T8 |
|
|
Power consumption of box, W, maximum |
300 |
|
|
Supply voltage, V |
~ 220 ± 5% |
|
|
Frequency, Hz |
50 ± 0,5 |
|
During the development and production of boxes, we are seeking to seamlessly combine design, ergonomics, technological effectiveness and final cost of products. There is a constant work aimed at the improvement of products.
Class 2 biosafety cabinet production duration according to customer’s order is up to 20 business days.
A cabinet is delivered to a customer in Ukraine only in rigid package.
The product has certificate>>, sanitary and epidemiological expertise report >> and technical specifications.>>.
|
Cabinet model |
Protection |
|||
|
Operator |
Environment |
Product |
||
|
БЛ-2 |
P |
P |
P |
|
|
БЛ-1 |
|
P |
P |
|
|
ББ-1 |
P |
P |
|
|
|
ВШ-1 |
P |
|
|
|
|
Б-1 |
|
|
P |
|
